Description
Product Overview
The ACEIRMC voltage transducer is a specialized module designed for accurate AC voltage measurement within 250V, featuring a high-precision ZMPT101B voltage transformer and onboard operational amplifier. It converts AC power signals into analog outputs with a sine wave form, where the median value is half the supply voltage (VCC), ensuring stable and reliable data acquisition. With package dimensions of 5.04 x 3.74 x 1.14 inches and a lightweight design at 4.6 ounces, this industrial-grade device supports a supply voltage range of 5-30V, making it versatile for various applications. Its construction includes exact sampling and compensation circuits, providing consistent performance in demanding environments.
Usage
This voltage transducer is ideal for industrial and scientific settings, such as power monitoring systems, electrical testing labs, and automation controls, where precise AC voltage data is critical. It suits engineers, technicians, and DIY enthusiasts working on projects that require real-time voltage tracking, energy management, or safety compliance checks. Common use cases include integrating into control panels, data loggers, or educational kits for hands-on learning about electrical measurements.
Why Choose Us
ACEIRMC stands out with its commitment to quality, utilizing high-precision components like the ZMPT101B transformer and advanced op-amp circuits for superior accuracy and durability. The module undergoes rigorous testing to meet industrial standards, offering a competitive edge through reliable performance and ease of integration. Customers benefit from a product backed by positive reviews and a focus on long-term value, ensuring it delivers consistent results in diverse electrical applications.
Key Features
- Measures AC voltage up to 250V with high accuracy for dependable power monitoring
- Outputs a sine wave signal with a DC component at 1/2 VCC for stable analog data
- Equipped with ZMPT101B high-precision voltage transformer for exact signal sampling
- Onboard amplifier circuit provides appropriate compensation and noise reduction
- Supports a wide supply voltage range of 5-30V for flexible integration
FAQ
What is the maximum AC voltage this module can measure?
The module safely measures AC voltage up to 250V, making it suitable for standard industrial and residential applications without risk of overload.
How does the output signal work for data acquisition?
It produces a sine wave analog output where the median value equals half the supply voltage, allowing easy interfacing with microcontrollers or data systems for accurate readings.
Can I use this transducer in high-temperature environments?
While it operates reliably in typical conditions, extreme temperatures may affect performance; refer to the manufacturer’s specifications for detailed environmental limits.
What power supply is required for proper operation?
A supply voltage between 5V and 30V is needed, ensuring compatibility with common power sources in industrial setups.
Is calibration necessary after installation?
No, the module is pre-calibrated for high precision, but periodic checks are recommended in critical applications to maintain accuracy over time.
